Project Details:
Wire Seal: Silicone rubber
Mating Seal: Silicone rubber
Cover: Glass filled PBT
Locking Wedge: PBT
- Accepts contact size 1.3 mm (up to 17 amps gold, up to 8 amps tin)
- 16-20 AWG
- 8, 14, 23, and 35 cavity arrangements
- PCB mount
- Rectangular, thermoplastic housing
- Integrated latch for mating
- Integrated wedgelock confirms contact alignment and retention
- Product specification documents: 108-1329 and 114-16016
