Project Details:
Flange Body: Thermoplastic
Flange Clip: Steel
Grommet: Silicone rubber
Jackscrew: Steel
Receptacle Threaded Inserts: Steel
Shell: Thermoplastic
Wedgelocks: Thermoplastic
- Accepts contact sizes 4 (100 amps), 8 (60 amps), 12 (25 amps), 16 (13 amps), and 20 (7.5 amps)
- 6-22 AWG
- 48, 60, 102, and 128 cavity arrangements
- Flange mount
- Rectangular, thermoplastic housing
- Jackscrew for mating
- Wedgelocks confirm contact alignment and retention
